High-voltage power stage with space-efficient evaluation board for smaller, tougher motor drives

高壓功率級，配備緊湊型評估板，適用于更小巧、更堅固的電機驅動器

Accelerating development of compact and reliable fans and pumps built with energy-efficient motors, STMicroelectronics has introduced the PWD5T60 three-phase driver with a ready-to-use evaluation board that supports flexible control strategies.

為加快緊湊、可靠型風扇和泵產品（采用節能電機）的開發，意法半導體推出了PWD5T60三相驅動器，該驅動器具有支持靈活控制策略的即用型評估板。

Suited to applications up to 500V, the PWD5T60 integrates a gate driver and six power MOSFETs with RDS(ON) of 1.38?, enabling the device to achieve an outstanding energy to area rating. Zero-drop bootstrap diodes are also built-in, requiring minimal external components to complete the circuit in only 30% of the board area of an equivalent driver built with discrete components. The propagation delays of high-side and low-side MOSFETs are closely matched, which eliminates cycle distortion and maximizes flexibility to set the operating frequency for optimum response and energy efficiency.

PWD5T60適用于高達500V的應用，集成了一個柵極驅動器和六個功率MOSFET，RDS(ON)為1.38?，能夠實現出色的能量面積比額定值。零壓降自舉二極管同樣內置，只需極少的外部組件，即可在等效驅動器（由分立器件構建）30%的板面積內完成電路。高邊/低邊MOSFET的傳播延遲緊密匹配，消除了周期失真，并能顯著提高設置工作頻率的靈活性，以實現理想的響應和能效。

The EVLPWD-FAN-PUMP evaluation board, released at the same time, helps developers quickly explore the value this driver can deliver in projects up to 100W. The board combines the PWD5T60 with an STM32G0 microcontroller (MCU) that can handle field-oriented control (FOC) or 6-step control of permanent magnet synchronous motors (PMSMs) and brushless DC (BLDC) motors. With configurable single or three-shunt sensing and leveraging the PWD5T60’s high feature integration to achieve a compact, circular form factor, the board is optimized for use with fans and pumps. The board also features a power-supply stage to generate 12V and 3.3V supply voltages for the application and comes with a complete AC line filter at the input.

同步發布的EVLPWD-FAN-PUMP評估板可幫助開發者快速探索該驅動程序在高達100W的項目中可提供的價值。該板將PWD5T60與STM32G0微控制器 (MCU) 相結合，可處理永磁同步電機 (PMSM) 和無刷直流 (BLDC) 電機的磁場定向控制 (FOC) 或6步控制。為搭配風扇和泵使用，意法半導體通過可配置的單分流或三分流傳感，專門對該板進行了優化，并利用PWD5T60的高功能集成來實現緊湊的圓形外形。該板還配有一個電源級，可為應用產生12V和3.3V的電源電壓，并在輸入端配備了完整的交流線路濾波器。

Featuring on-board bus-voltage sensing, the EVLPWD-FAN-PUMP board helps utilize the PWD5T60’s safe design that provides undervoltage lockout (UVLO) for each bootstrap section to prevent operation in dangerous or low-efficiency conditions. Engineered for robustness, the PWD5T60 also features cross-conduction prevention with interlocking and pre-programmed default deadtime to ensure failsafe protection against shoot-through currents. In addition, excellent below-ground robustness ensures faultless performance.

EVLPWD-FAN-PUMP板具有板載總線電壓傳感功能，有助于利用PWD5T60的安全設計，為各自舉部分提供欠壓鎖定 (UVLO)，以避免在危險或低效條件下運行。PWD5T60專為打造穩健性而設計，具有互鎖和預編程默認死區的防交叉?zhèn)鲗Чδ?，以確保對擊穿電流的故障安全保護。此外，其出色的地下穩健性也保證了出色的無故障性能。

The PWD5T60 has a smart shutdown feature that uses a comparator for fast-acting overcurrent prevention. The output turns off immediately when a fault is detected, while the subsequent output-disable duration is programmed by connecting a capacitor and optional pull-up resistor to a dedicated pin. The turnoff response is unaffected by these components, letting product developers optimize the duration to allow time for faults to clear while always ensuring instant turn-off.

PWD5T60具有智能關機功能，可通過比較器來快速防止過電流。當檢測到故障時，輸出會立即關閉，隨后將電容器和上拉電阻器（可選）連接到專用引腳，以此來對輸出禁用持續時間進行編程。關閉響應不受此類組件的影響，讓產品開發者得以優化持續時間，以便有充足的時間來清除故障，并確保關閉的即時性。

The driver has a wide input supply voltage range from 9V to 20V for optimum flexibility, while CMOS/TTL-compatible logic inputs down to 3.3V simplify interfacing with a host controller.

該驅動器具有從9V到20V的寬輸入電源電壓范圍，可實現出色的靈活性，而低至3.3V的CMOS/TTL兼容邏輯輸入則簡化了與主機控制器的接口連接。

The PWD5T60 is in full production and available in a compact 12mm x 12mm VFQFPN package only 0.95mm high, from $3.28 for orders of 1000 pieces.

PWD5T60現已全面投產，采用緊湊型12mm x 12mm VFQFPN封裝（高度僅0.95mm）；千片起訂單價3.28美元。

The EVLPWD-FAN-PUMP evaluation board is available now from the eSTore, at the budgetary price of $102.00. The board delivers plug-and-play convenience leveraging FOC and 6-step control firmware in the X-CUBE-MCSDK motor-control software development kit available free of charge at st.com.

EVLPWD-FAN-PUMP評估板現可從電子商城購買，建議零售價102.00美元。該板利用X-CUBE-MCSDK電機控制軟件開發套件中的FOC和6步控制固件提供即插即用的便利性，該套件可在st.com免費獲得。
